GoodGavin 3: 2 楼

下面比较了一下用工具添加API前后应用程序的变化：

正在比较文件 crackme.exe 和添加API后的CRACKME.EXE

000000CE: 04 05  添加了一个块 ..idata
00000119: 50 60  SizeOfImage，映像装入内存后的总尺寸，增加了块，所以这个相应增加
00000148: 40 00  输入表地址由2040改为5000
00000149: 20 50  输入表地址由2040改为5000

..idata  RAddress = VAddress - (VOffset - ROffset )
               = 5000 - (5000 - 2400) = 2400

00000260: 00 2E  添加块的块信息
00000261: 00 2E  添加块的块信息
00000262: 00 69  添加块的块信息
00000263: 00 64  添加块的块信息
00000264: 00 61  添加块的块信息
00000265: 00 74  添加块的块信息
00000266: 00 61  添加块的块信息
00000269: 00 10  添加块的块信息
0000026D: 00 50  添加块的块信息
00000271: 00 02  添加块的块信息
00000275: 00 24  添加块的块信息
00000284: 00 02  添加块的块信息
00000287: 00 E0  添加块的块信息

下面是PEditor添加的使用他的标志信息
**************** Modified with PEditor 1.7 by yoda & M.o.D. -> come.to/f2f ****************
00000290: 00 2A
00000291: 00 2A
……
……
000002EE: 00 2A
000002EF: 00 2A

FC: 添加API后的CRACKME.EXE 比 crackme.exe 长（这个应该指的是添加的新块）

内容如下：

      原来程序输入表IID的拷贝：
00002400h:[A0 20 00 00 00 00 00 00 00 00 00 00 18 21 00 00 ; ?...........!..
00002410h: 24 20 00 00 7C 20 00 00 00 00 00 00 00 00 00 00 ; $ ..| ..........
                                 添加的IID
00002420h: 9E 21 00 00 00 20 00 00][6D 50 00 00 00 00 00 00 ; ?... ..mP......
00002430h: 00 00 00 00 50 50 00 00  6D 50 00 00]00 00 00 00 ; ....PP..mP......
00002440h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002450h: 75 73 65 72 33 32 2E 64 6C 6C 00 00 00 47 65 74 ; user32.dll...Get
00002460h: 44 6C 67 49 74 65 6D 54 65 78 74 41 00 5B 50 00 ; DlgItemTextA.[P.
00002470h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002480h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002490h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024a0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024b0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024c0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024d0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024e0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000024f0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002500h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002510h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002520h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002530h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002540h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002550h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002560h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002570h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002580h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
00002590h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025a0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025b0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025c0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025d0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025e0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................
000025f0h: 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 ; ................

再看一下IID: OrignalFirstThunk TimeDateStamp ForwardChain    Name             FirstThunk
         6D 50 00 00    00 00 00 00    00 00 00 00    50 50 00 00    6D 50 00 00
相对偏移: 0x506DH                                           0x5050H          0x506DH
绝对偏移: 0x246DH                                           0x2450H          在程序运时被初始化
                                                               user32.dll
RAddress = VAddress - (VOffset - ROffset )
      = 506D - (5000 - 2400) = 506D - 2C00 = 246D
所以新添加的DLL的FirstThunk和OrignalFirstThunk的地址相同，相对偏移地址为506D，绝对偏移地址为2460

因此添加API的操作应该是：
1、添加一个新块
2、更改PE文件头的输入表地址到指定位置
3、在指定位置放置原输入表的IID拷贝，并追加新添加的IID
4、在新块中为新添加的IID加入希望添加的API
5、（猜测）在更改过的程序中作标记，以便不用在每次添加API时都添加新的段（直接更改自己曾经添加过的段）

另外突然发现PEditor添加API后会生成一个文本文件：“应用程序名_IData.txt”,里面便是告诉我们如何调用添加的API，汗！

GetDlgItemTextA - call dword ptr [0040506D]

不过如果提前发现了，可能暂时就不去分析PE文件格式了

2010-2-18 22:01
